Operation steps and grading of laser leveling machine

Publication time:2022/03/03 18:35:12 Reading volume:434 Source: 广东玛哈特智能科技有限公司

Benchmarking and Machine Tuning Steps

1. Choose a reasonable location to place the tripod (avoid places with many people, cars, air vents, vibration, and glass). The height of the tripod is higher than the height of the normal helmet, generally about 1.8 meters. Look, the horizontal bubble on the tripod must be inside the circle.

2. After supporting the tripod, turn on the transmitter switch. After normal work, use the lever (screw on the small receiver) to set the reference point (generally the reference point is provided by Party A). Turn on the small receiver on the handle, and when the middle light is on, loosen the bolt to display "0" as a reference.

3. After setting the reference point, start adjusting the machine.

4. Place an object almost as high as the reference plane under the vibrating plate in front of the machine (for example, when the object hits the ground 10 cm, place objects about 10 cm on both ends of the vibrating plate)

5. After the padding, start the machine, first press the "Auto key" to align the body. Once aligned, one is at the machine console and one is leaning against the left and right scrapers with a manual lever. Adjust the scrapers on both sides to the "0" point by pressing the "left and right" buttons, and measure the left and right scrapers a few times to make sure they are both at the "0" point.

6. After the scraper is adjusted, start to adjust the two large receivers on the top of the scraper of the machine. Large receivers also need to check the lights on both ends until the green light turns on. After tightening the bolts, hand click on the big receiver and see if the green light changes.

7. After the large receiver is aimed at the light, press the three buttons on the operation panel (left button, front and rear balance button of the fuselage, right button), and press the button to disturb. After disturbance, press "Auto key" to make the machine level automatically.

8. When the large receivers at both ends keep the green light, turn off the automatic key, hold the hand-held rod against the scrapers at the left and right ends, and check the error of the scrapers at both ends. The error at both ends is within "5" mm, and the construction can be done normally. If it exceeds "5" mm, just press (left push rod, body front and rear balance, right push rod) to upset again, then press the automatic button, then turn off the automatic button, and then adjust the error of the scrapers at both ends, usually Two or three times.


Machine construction steps

1. After the machine is turned on, press the balance button (up button) on the front and rear of the fuselage to tilt the fuselage forward, press the handle, and press the start switch to advance to the concrete to be constructed.

2. After the fuselage is placed on the concrete, press the auto button to automatically align the fuselage. After the green light in the middle of the two large receivers is on, set the walking speed at "3" and do not exceed "4". Then press the enter key, the machine will walk about 10 cm, and then press the vibration key.

3. When the machine is walking, control the left and right direction keys to keep the machine in a straight line.

4. When the concrete surface is flat, turn off the automatic key and the vibration key at the same time, and then press the Enter key to return to the neutral position.

5. After the machine pulls the first bar, continue to complete the subsequent grinding, and repeat the operations in sequence according to the first bar.

Duplicate carefully, making sure it's "5" mm above the reference plane.

In the concrete summer planting area, after the machine completes the automatic operation, turn off the automatic key, lift the scrapers on the left and right sides, and complete the leveling manually.

According to the dry humidity of concrete, choose "automatic" and "manual" mode reasonably.

In automatic mode, there is too much material on the scraper to peel off manually. If there is not enough material, it can be supplemented manually, with good cooperation, the effect is good.
